Cta-2006 Compliant
Number of Channels
1
Total Power
(Sum of Rated Power)
(Sum of Rated Power)
100 Watts
Rated Power
(RMS Continuous Power)
(RMS Continuous Power)
60 Watts x 1 @ 4-Ohm
100 Watts x 1 @ 2-Ohm
100 Watts x 1 @ 2-Ohm
Dynamic Power
(PVC/PowerCube®)
(PVC/PowerCube®)
61 Watts x 1 @ 4-Ohm
109 Watts x 1 @ 2-Ohm
109 Watts x 1 @ 2-Ohm
Bridgeable
No
Frequency Response
60Hz to 20kHz +/- 1.0dB
Total Harmonic Distortion (THD+Noise)
4-Ohm: <1.0%
2-Ohm: <1.0%
2-Ohm: <1.0%
Crossover Controls
High-Pass:
Selectable 60Hz, 80Hz, 100Hz @ 12dB/octave Butterworth
Selectable 60Hz, 80Hz, 100Hz @ 12dB/octave Butterworth
Remote Controls
Visual Indicators
Power/Protect LED
Cooling
Convection
Operating Voltage
9 - 16 VDC
Recommended Fuse
(Not Included)
(Not Included)
Average Current Draw (13.8V Music)
Max. Current Draw (13.8V Sinewave)
Dimensions (H x W x D)
1.3 x 3 x 3.9 (in)
3.3 x 7.62 x 9.91 (cm)
3.3 x 7.62 x 9.91 (cm)
