General Specifications
- Transducers
- 8x 2.75”(70mm) woofers, 2x 1”(25mm) Tweeters, 4 x 7.2"(182.8mm) x3"(76.2mm) Racetrack Passive Radiators
- Output Power
- 300WRMS, 600W PEAK (IEC60268)
- THD at Rated RMS Power
- < 1%
- Voltage Range: 9.6 - 16VDC
- Quiescent Current Draw
- < 0.9A
- Maximum Current Draw
- 40A
- Frequency response
- 45Hz-40kHz
- Signal-to-noise Ratio
- > 80 dB
- Cable type
- 10 AWG
- Cable length
- 12 Feet (3.66m)
- Bluetooth® Version
- 5.3
- Bluetooth® profile
- A2DP V1.3, AVRCP V1.6
- Bluetooth® transmitter frequency range
- 2400 MHz – 2483.5 MHz
- Bluetooth® transmitter power
- ≤ 15 dBm (EIRP)
- Aux-In
- 2Vrms(0.35Vrms - 2Vrms), 4Vrms(0.7Vrms - 4Vrms), 6Vrms(1.05Vrms - 6Vrms) (3.5 mm connector)
- Aux-Out
- 2 Vrms (3.5 mm connector)
- USB format
- FAT16, FAT32
- Soundbar Dimension (L x W x H)
- 35-11/32" x 5" x 4-5/8" (897.5 x 126.7 x 118mm)
- Soundbar Weight
- 20.83 lbs (9.45 kg)
- Packaging dimensions (W x H x D)
- 38.2" x 9" x 7.6" (971 x 229 x 193mm)
- Gross weight
- 27.5 lbs (12.52 kg)
