Product highlights:
- 5-channel car amplifier
- 40 watts RMS x 4 + 200 watts RMS x 1 at 4 ohms
- 60 watts RMS x 4 + 300 watts RMS x 1 at 2 ohms
- 120 watts RMS x 2 bridged at 4 ohms + 300 watts RMS x 1 at 2 ohms
- channels 1-4:
- Hi-Res Audio Certified (frequency response: 10-40k Hz)
- variable high-pass filters (50-400 Hz, 12 dB/octave)
- sub channel:
- variable low-pass filter (50-400 Hz, 24 dB/octave)
- variable bass boost (0-12 dB at 50 Hz)
- optional wired remote available
More Info:
- preamp and speaker-level inputs
- speaker-level inputs handle up to 10V
- RCA adapters required for speaker-level input
- signal-sensing turn-on with speaker-level inputs
- wiring and hardware not included with amplifier
- 4-gauge power and ground leads recommended
- fuse rating: 30A x 2
- dimensions: 11.88"W x 2.23"H x 8.28"D
- warranty: 1 year
- MFR # S2-A55V
- Item # 500S2A55V
- California customers: Please click here for your Proposition 65 WARNING.
What's in the box:
If you need assistance accessing this owner's manual, please give us a call.
- 5-Channel amplifier
- Two 30-amp ATO fuses (installed)
- 2 End caps
- Four 3/4" Screws
- Four 1/4" screws
- 2mm Allen key
- Owner's manual (En/ Sp/ Fr/ Others)
- Alpine Verification Certificate
- Warranty information
- Power supply note
- On-line product registration information
